FAXON MATCH SERIES 12.5" 338 ARC GUNNER 1:8T COMPLETE UPPER - SUPPRESSOR READY
FaxonDescription
AR15 Upper Receivers › Complete Uppers, Suppressor Ready › Match Series 12.5″ 338 ARC
What’s on This Upper
Every major part is a Faxon part that is also sold on its own; each card links to its product page, specs, and reviews.
BARREL
Match Series 12.5″ Gunner 338 ARC barrel ›
416-R Stainless, QPQ Nitride, 1:8 twist, pistol-length gas, 5/8x24 muzzle. Every barrel is borescoped, bore and groove air gauged, headspace gauged with GO/NO-GO gauges, and 100% wet magnetic particle inspected before it ships.
UPPER RECEIVER
338 ARC Enhanced Forged upper ›
7075-T6 forging, Type III hard coat, forward assist and ejection port cover installed. Feed ramps cut for the 338 ARC case and Faxon’s extended-ramp 338 barrel extension.
HANDGUARD
Streamline aluminum M-LOK 10.75″ handguard ›
6061 aluminum, hard coat anodized, M-LOK slots on all 8 surfaces, free-floated.
GAS BLOCK
Faxon patented adjustable .750" low-profile gas block ›
14 detented settings; the adjustment moves the gas tube, so the screw never sits in carbon. 4140, flash nitride, 3 set screws.
GAS TUBE
Pistol-Length stainless gas tube ›
Faxon’s gas tubes are made from 304 seamless stainless steel tubing.
MUZZLE DEVICE
MuzzLok® Plan B compatible flash hider ›
5/8x24, .375″ bore. Left-hand MuzzLok® timing nut: timed without crush washers or shims, and ready for a Plan B to HUB adapter.
BOLT CARRIER GROUP
6.5 Grendel / ARC Gunner Lightweight Type 2 BCG, nitride ›
Lightweight carrier, Type 2 bolt with .136 firing pin, superfinished and nitrided.
CHARGING HANDLE
Faxon Edition BREEK® Sledgehammer charging handle ›
Ambidextrous and gas-blocking, built for rifles that run suppressed.
Not included: lower receiver, suppressor, Plan B to HUB adapter, optic.
Barreled, Complete, or Suppressor Ready?
Faxon builds each upper in up to four configurations. A barreled upper has the receiver, barrel, gas system, handguard, and muzzle device installed, with no bolt carrier group or charging handle. A complete upper adds both, so it is ready to pin to a lower. Suppressor ready versions swap in a MuzzLok® Plan B compatible flash hider and, on gas guns, Faxon’s patented adjustable gas block, so a suppressor mounts with one adapter and the gas can be tuned to it. This one is the complete upper, suppressor ready.
What a 338 ARC Upper Needs
| Fires | 338 ARC |
| Bolt | Type 2 bolt (.136 firing pin) (included) |
| Magazines | Magazines made for 338 ARC |
| Lower | Any mil-spec AR-15 lower receiver |
| Buffer | Standard AR-15 carbine buffer system; tune the adjustable gas block to it |
338 ARC is Hornady’s heavy-bullet AR-15 cartridge, built for suppressed subsonic work. SAAMI twist is 1:8; Faxon also makes a 1:5 for heavier subsonics in short barrels. This barrel is 1:8, with a custom-milled extension and extended feed ramps, in Faxon’s 338 ARC upper whose ramps are cut to match.
Suppressor Ready, Explained
1. MOUNT
Thread a Plan B to HUB adapter (titanium, $95 or stainless, $65; extended versions too) onto the MuzzLok® flash hider. It converts the Plan B interface to the 1.375x24 HUB thread.
2. SUPPRESSOR
Thread on a .36 cal HUB-mount can. Faxon’s: HARMONIX® ION .36 (titanium, the lightweight pick), HARMONIX® Sentry .36 (Haynes 282, built for heat), CORESYNC® .36 (removable core).
3. TUNE
Start with the gas block fully open and confirm it runs. Close it one click at a time, a few rounds per click, until the bolt stops locking back on an empty magazine, then open it one or two clicks. Note the count.
4. RUN IT BOTH WAYS
Count back to your unsuppressed setting when the can comes off. The detents hold the setting under recoil.
Adjust with the rifle unloaded and the block cool. Suppressor purchase requirements are listed on each suppressor’s page; federal, state, and local laws apply.
Why a Lightweight Carrier Gets an Adjustable Gas Block
A lighter carrier needs less gas to cycle, and a suppressor adds back-pressure. Without a way to reduce gas, the bolt runs fast and hard: more recoil, more gas to the face, and more wear on the carrier, extension, and buffer. Faxon’s rule runs one way: if a build gets a lightweight carrier, it gets an adjustable gas block. This upper has both, so you tune it once for your ammunition and suppressor and it runs soft.
How It’s Built and Inspected
| Barrel | 416-R stainless barrel, 5R button rifled; Stress relieved, then profiled true to the bore; Salt-bath QPQ nitride inside and out; NP3 nickel-Teflon barrel extension torqued to 150 ft-lb |
| Barrel inspection | Borescoped after reaming, rifling, and chambering; bore and groove air gauged; chamber checked on a CMM program first and last of every run; muzzle threads gauged; headspace gauged; 100% wet MPI |
| Upper receiver | 7075-T6 forging, Type III hard coat. Barrel threads gauged on every receiver, CMM checked every shift. Feed ramps cut for the 338 ARC case and Faxon’s extended-ramp 338 barrel extension. |
| Assembly | Assembled, inspected, and packed by Faxon in Greater Cincinnati, Ohio |
| Process control | Full CMM first-article inspection after any machine maintenance, tool change, or part change, and at least every 30 days; material certs checked at receiving; stress relief and nitride certified by lot |
Finish the Rifle
This upper pins to any mil-spec AR-15 lower. Faxon makes three, all from 7075-T6 forgings with an upper-to-lower tensioning screw to take out receiver play. The lower is the serialized part, so it ships to an FFL; the upper doesn’t.
BUILD YOUR WAY
Forged Lower with Completion Kit ›
Pins, springs, fire control, grip, and a B5 trigger guard. $170
Specifications
| Caliber / chamber | 338 ARC |
| Barrel | Match Series 12.5″ Gunner, 416-R Stainless, QPQ Nitride |
| Twist | 1:8, 5R button rifled |
| Gas system | Pistol-length; pistol-length 304 stainless tube |
| Gas block | Patented adjustable .750" low-profile gas block, 3 set screws, 14 settings |
| Muzzle | 5/8x24; MuzzLok® Plan B compatible flash hider, 5/8x24, .375″ bore |
| Handguard | 10.75″ Streamline aluminum, M-LOK on all 8 surfaces, free-float |
| Bolt carrier group | 6.5 Grendel / ARC Gunner Lightweight Type 2 BCG, nitride |
| Charging handle | Faxon Edition BREEK® Sledgehammer charging handle |
| Upper receiver | 338 ARC Enhanced Forged upper, 7075-T6, Type III hard coat, forward assist and port cover |
| Assembled in | Greater Cincinnati, Ohio, USA |
| Warranty | Faxon Lifetime Guarantee |
Fitment
| Lower receiver | Any mil-spec AR-15 lower |
| Magazines | Magazines made for 338 ARC |
| Bolt | Type 2 bolt (.136 firing pin) |
| Suppressor | .36 cal HUB-mount can via a Plan B to HUB adapter |
| Optics | Flat-top Picatinny upper; M-LOK handguard for lights and lasers |
| FFL | Not required for the upper; state and local laws apply |
What Reviewers and Owners Say About These Parts
This upper is new, so it has few reviews of its own yet. Every major part on it is sold on its own, so here is what independent reviewers and Faxon customers have said about the barrel, carrier, handguard, gas block, and receiver.
RECOIL
A 338 ARC hunting build on a Faxon upper, barrel, and gas block.
“their uppers and barrels are cut with very generous feed ramps to aid in reliability.”
OPTICSPLANET
Faxon 338 ARC Upper Receiver Reviews ›
Verified buyer on the 338 ARC Enhanced Forged upper.
“The larger feed ramps are excellent, and fit closer to the ramps on the barrel extension.”
RECOIL
338 ARC: Testing Hornady’s New Subsonic ›
Ran Faxon’s adjustable gas block on a suppressed subsonic 338 ARC build.
“It’s easy to use, easy to tune and works just right.”
“The barrel was very accurate.”
William R. Hood, Sr., 12.5″ Gunner 338 ARC barrel, FaxonFirearms.com
“No worries about carbon lock with this design, and very easy to maintain the setting you want.”
Pat, gas block, FaxonFirearms.com
“this receiver with the enlarged feed ramps solved the problem.”
John Rankin, upper receiver, FaxonFirearms.com
Average ratings on FaxonFirearms.com, out of 5 stars: 12.5″ Gunner 338 ARC barrel: 5.0; gas block: 4.9; upper receiver: 5.0.
Compare the Match Series 12.5″ 338 ARC Uppers
| Upper | BCG + charging handle | Muzzle | Gas block | MSRP |
|---|---|---|---|---|
| Barreled, suppressor ready | Not included | MuzzLok® Plan B compatible flash hider | Adjustable | $660 |
| Complete, suppressor ready (this upper) | Included | MuzzLok® Plan B compatible flash hider | Adjustable | $978 |
Match Series 12.5″ 338 ARC Complete Upper, Suppressor Ready FAQs
What comes on this upper, and what doesn’t?
Included: 338 ARC Enhanced Forged upper, 12.5″ Match Series Gunner 338 ARC barrel, 10.75″ Streamline aluminum M-LOK handguard, patented adjustable .750" low-profile gas block, pistol-length stainless gas tube, MuzzLok® Plan B compatible flash hider, 6.5 Grendel / ARC Gunner Lightweight Type 2 BCG, nitride, Faxon Edition BREEK® Sledgehammer charging handle. Not included: lower receiver, suppressor, Plan B to HUB adapter, optic.
What’s the difference between a barreled upper and a complete upper?
A barreled upper has the receiver, barrel, gas system, handguard, and muzzle device installed but no bolt carrier group or charging handle. A complete upper includes both and is ready to pin to a lower. Suppressor-ready versions add a MuzzLok® Plan B compatible flash hider and Faxon’s patented adjustable gas block.
Will this upper fit my lower?
Yes, if it’s a mil-spec AR-15 lower. Mil-spec uppers and lowers share the same pin locations and dimensions. Billet receivers from different makers can fit tighter or looser; Faxon lowers include a tensioning screw to take out play. AR-10, AR-9, and dedicated-lower systems aren’t interchangeable with AR-15 uppers.
Do I need to check headspace?
Every Faxon barrel is headspace gauged with GO/NO-GO gauges when the extension goes on, and the BCG installed is the one this upper ships with. Checking headspace with GO/NO-GO gauges for the bolt you run is always good practice, and it’s a must any time you swap in a different bolt.
What bolt and magazines does a 338 ARC upper use?
Bolt: Type 2 bolt (.136 firing pin) (installed). Magazines: Magazines made for 338 ARC.
What ammunition does it shoot?
338 ARC. The SAAMI 1:8 twist runs both supersonic and subsonic 338 ARC loads.
How do I tune the adjustable gas block?
With the rifle unloaded and the block cool, start fully open and confirm it runs. Close it one click at a time, firing a few rounds per click, until the bolt stops locking back on an empty magazine, then open it one or two clicks. Note the count and retune when you add or remove the suppressor or change to a very different load. It takes a 3/32″ hex key or a flat screwdriver.
What do I need to mount a suppressor?
A Plan B to HUB adapter (titanium $95 or stainless $65, standard or extended) and a .36 cal HUB-mount suppressor, such as Faxon’s HARMONIX® ION .36 or HARMONIX® Sentry .36.
Why does this upper pair a lightweight BCG with an adjustable gas block?
A lighter carrier needs less gas to cycle, and a suppressor adds back-pressure. Faxon’s rule is that any build with a lightweight carrier gets an adjustable gas block, so you can tune the gas down instead of beating up the carrier, extension, and buffer.
Is a 12.5″ upper legal?
A barrel under 16″ on an AR-15 rifle lower makes a short-barreled rifle under federal law; on a pistol lower it makes an AR pistol. Rules vary by state and locality and can change, so know and follow the laws where you live before you build. Faxon doesn’t provide legal advice.
What makes a good AR-15 upper, and how does this one compare?
Start with the barrel: steel, rifling, finish, and inspection. This one is 416-R Stainless, 5R button rifled, QPQ nitrided, borescoped, air gauged, headspace gauged, and 100% MPI inspected. Then a forged 7075-T6 receiver, a gas system matched to the barrel length (pistol-length here), a free-float M-LOK handguard, and, on a complete upper, a quality BCG. Faxon makes the barrel, receiver, gas block, and muzzle device, and assembles the upper in Ohio under a Lifetime Guarantee.
Nitride or chrome lining: which is better?
Chrome lining still has its place, mainly sustained automatic fire. For the vast majority of shooters, Faxon’s salt-bath QPQ nitride does what they need and more: it hardens the bore and exterior, resists corrosion, adds virtually nothing to the dimensions (a few ten-thousandths of an inch, about a tenth the width of a human hair), and needs little to no break-in.
Does the upper ship to an FFL?
No. The upper isn’t the serialized part of an AR-15, so it doesn’t require an FFL. Faxon lowers do. State and local laws on barrel length, threaded barrels, and muzzle devices still apply.
Where is it made, and what is the warranty?
Faxon makes the barrel, receiver, gas block, and MuzzLok® devices in Greater Cincinnati, Ohio, and assembles the upper there. It’s covered by the Faxon Lifetime Guarantee.
Build the rest of the rifle
Pin it to a lower, mount a can, and go shoot.
