FAXON DUTY SERIES 10.5" 9MM BARRELED UPPER - SUPPRESSOR READY

AR15 Upper Receivers › Barreled Uppers — Suppressor Ready › Duty Series 10.5″ 9mm  |  Works with: 9mm BCG • Breek® charging handle • 9mm muzzle devices

Why a Dedicated Blowback 9mm Upper

A 9mm cartridge doesn’t need a gas system to cycle an AR. The bolt carrier’s own mass and the buffer hold the action closed until pressure drops, then the case pushes it rearward — straight blowback. That is why this upper has no gas port, gas block, or gas tube, and why its bolt carrier group is a heavy, full-mass 9mm carrier instead of a 5.56 BCG. Fewer parts, less to clean, nothing to tune.

The barrel is purpose-built for it. Instead of a separate barrel extension, the Light Taper barrel has a one-piece .999″ receiver shank with a pressed-in index pin, and its chamber mouth is radiused and chamfered so it feeds from Glock®-pattern and Colt-pattern 9mm lowers alike. The Light Taper profile — .675″ tapering to .625″ — keeps the 10.5″ barrel at 1.03 lb.

What “Duty Series” Means

Duty Series is Faxon’s 4150 CMV barrel line: the M4/M16 barrel alloy, salt-bath QPQ nitrided inside and out. Nitride is a diffusion treatment, not a plating, so it hardens the bore and exterior and adds corrosion resistance while adding virtually nothing to the surface. It is the right combination for a barrel that will be shot hard, carried in the weather, and cleaned when there is time.

What’s in the Box

Also in the box: chamber flag, owner’s manual, and warranty registration card.

Bill of Materials

The exact Faxon parts this barreled upper is assembled from, so you can check fitment, plan upgrades, or order a spare.

Build It Out

Faxon parts that fit this upper. A BCG and a charging handle finish it.

Duty Series 10.5″ 9mm Barreled Upper FAQs

What lower does this upper work with?

A Glock®-pattern or Colt-pattern 9mm AR lower. The barrel’s chamber mouth is radiused and chamfered to feed from both, and the Faxon Gen 2 9mm BCG is built for both. A standard 5.56 AR-15 lower and magazine will not feed 9mm.

Does it need a gas block or gas tube?

No. It is a straight-blowback 9mm, so there is no gas port, gas block, or gas tube. The carrier’s mass and the buffer do the work.

What buffer should I run?

A heavy 9mm buffer, 5.5 to 8 oz, with a standard carbine spring — or whatever buffer system your 9mm lower is designed around. A standard 3 oz carbine buffer is too light for blowback 9mm.

Does it include a bolt carrier group and charging handle?

No. This is a barreled upper: barrel, handguard, and muzzle device on a forged upper with the parts kit installed. Add a 9mm blowback BCG — the Faxon Gen 2 9mm PCC BCG fits — and any mil-spec charging handle. The complete version ships with both installed.

Can I put this 10.5″ upper on a rifle lower?

Only if that lower is registered as a short-barreled rifle. A 10.5″ barrel on a lower with a stock is an SBR under the National Firearms Act. On a pistol lower it builds an AR pistol. Check your state and local law before you assemble it.

How does the Plan B flash hider mount a suppressor?

The MuzzLok® Plan B flash hider threads onto the 1/2x28 muzzle and is timed with a left-hand nut, so it comes off without shims or crush washers. Behind the tines is a 29/32-24 Plan B interface that a suppressor with a Plan B-compatible mount threads onto. It is rated for 9mm and smaller bores.

What ammunition does it shoot?

9mm Luger from 115 to 147 gr, standard or +P. 147 gr loads are subsonic, the usual choice for running suppressed.

Where is it made, and what is the warranty?

The barrel is made start to finish in Faxon’s Greater Cincinnati, Ohio plant, and the upper is assembled there. It is covered by the Faxon Lifetime Guarantee.

Barrel dimensions are from the Faxon engineering print; weight is for the barrel alone. Components are listed from the Faxon build sheet for this SKU. Lower receiver, buffer, and magazines sold separately. Covered by the Faxon Lifetime Guarantee.
